DESCRIPTION
|
PART No.
|
WT. Kg
|
|
CASE / DAVID
BROWN
Late models with solid reinforcing bars under flat top mudguards,
4 post frame bolts on top of mudguards.
|
CASE 2
(4 post)
|
56
|
|
770-850-880-900-950-990 IMPLEMATIC
only
(old red models with curved guards)
|
CASE 1
|
71
|
|
880 (3 cyl)-990-995-996-1200-1210-1212
(white colour SELECTOMATIC models). Round or square (non reinforced
guards)
|
CASE 4
|
102
|
|
780-885 (white colour) curved
or square guards-1190-1194
|
CASE 6
|
75
|
|
CHAMBERLAIN
CHAMPION 9G-9G CANELANDER
|
CHAMB 9G
|
83
|
|
COUNTRYMAN Mark 1-2-3-4 COUNTRYMAN
6
|
CHAMB 4
|
78
|
|
306-C670-236
|
CHAMB 3
|
80
|
|
354-C6100 (without 3 point linkage)
|
CHAMB 2
|
102
|
|
FIAT 411R-415-450-500-540-550-600-640
STD OR D.T
Note: for models with curved guards and round axle housing only
(most common). Not suitable for high clearance axle setting.
|
FIAT 1
|
71
|
|
513R
|
FIAT 4
|
120
|
|
615
|
FIAT 2
|
82
|
|
650-650S-750-750S
|
FIAT 3
|
85
|
|
FORD 1700-1710-1900-1910
square axle models only.
|
F6
|
51
|
|
DEXTA-2000-2100-3000
Economy frame (hoop type) FORD DEXTA-2000-2100-3000
(will not accept canopy)
|
MF1 or
MF1F (folding)
|
44
53
|
|
EMF1
|
36
|
|
SUPER DEXTA -2600-3600 (allows
for handbrake)
|
F3
|
70
|
|
MAJOR-POWER MAJOR-SUPER MAJOR-3610-4000-4100-4600
4610 (4610 with reinforced guards req spacer block)
5000-5600-5610-6600-6610-7000-7600
|
F1 or
F1F (folding)
|
80
90
|
|
|
Narrow (cane models) 4000-4600-5000-5600
5610-6600-6610-6700-7000-7600
|
Curved Mudguards
|
|
Square Mudguards
|
|
F4N
|
95
|
|
F4NSQ
|
100
|
|
8000-8600-9600
|
F2
|
131
|
|
I.H.C.
- CASE
B250-B275
|
F1 or
F1F (folding)
|
80
90
|
|
A414-434-374-384-444 (handbrake
on mudguard)
|
as above +
KHB1 h/brake kit
|
82
|
|
B414 (UK. built - handbrake not
on mudguard)
|
F1 or
F1F (folding)
+ KHB2 h/brake kit
|
81
|
|
454-474-475-484-485-574-584-585-674-684-685-784-885
|
IHC5
|
90
|
|
A0S6-AW6-AW7-554-(564 with round
axle housing)
|
IHC4
|
90
|
|
564 with square axle housing
|
IHC4SQ
|
90
|
|
686-696-756-766-796-866-966-986-996-1066-1086
|
IHC6
|
146
|
|
624 German model with round axle
|
IHC7
|
110
|
|
JOHN DEERE
1010-1020-1030-1120-1130-1630-2010-2020-2120-3010
Not suitable for models fitted with high mounted seats
If in doubt order JD2 below
|
F1 or
F1F (folding)
|
80
90
|
|
Above models if fitted with high
mounted seats + 850-950-1040
1050-1140-1640-2030-2040-2130-2140-3020-3120-3130-3140-4020
*if spacing blocks under mudguards order with 14" bolt kit *
|
JD2
**
|
80
|
|
4230-4240-4250-4420-4430
|
JD3
|
145
|
|
KUBOTA
L185-L245-L295
|
KB2
|
34
|
|
L345
|
KB1
|
57
|
|
M4050
|
F1 or
F1F (folding)
|
80
90
|
|
LEYLAND
154-BMC MINI
|
LEY2
|
47
|
|
245-253-255-262-270-272-285-344-384
|
LEY1
|
82
|
|
MASSEY FERGUSON
TE20-MF30-130-35-135-148-240
Economy frame (hoop type)
TE20-MF35-135-148
(will not accept canopy)
|
MF1 or
MF1F (folding)
|
44
53
|
EMF1
|
36
|
|
MF65-165-168-175-178-185-188-250-265-275-290-298-675-690
(round or square axles) *high clearance tractors with thick (6")
mudguard spacers-order 14" bolt kit (special)
|
F1 or
F1F (folding)
|
80
90
|
|
MF550-575-590 (4 post frame)
|
MF550 (4 post)
|
95
|
|
MF50A-MF50B Industrial wet brakes
(square axle)
F.O.P. Falling Objects Industrial Frame
|
MF50 (4 post)
|
210
|
|
NUFFIELD 3/42-4/42-3/45-4/60-4/65-10/42-10/60-UNIV
DM4
|
LEY1
|
82
|
|
SAME
Sametti V-Italia-Atlanta-Falcon-Falcon DT-Condor-Leone S1 76 Centauro-Taurus-Corsaro-Minitaurus-Centurion-Saturno
|
S1
|
76
|
|
SHIBAURA 1640-2240-3040-4040
(square axle model only)
|
F6
|
51
|
|
UNIVERSAL (UTB) FARMLINER
445-DT445-500-530-550-640
Models with round axle housing - std clearance only
|
FIAT1
|
71
|
