APPLICATION
|
ENGINE
KIT
|
PISTON/ LINER
(1 Cyl)
|
RING SET
(1 Cyl)
|
PISTON
|
LINER
FINISHED
|
LINER SEMI
FINISH
|
|
MF65 MKI
A4-192 engine
Identify By: 88.92mm
bore
|
EK10
EKM10
EKMC10
Valve Train Kit:
VK16
|
B2917
|
B5154
=41158063
745823M91
|
B6917
=55274
739845M91
|
B7542
=0530002
731595M1
|
N/A
|
|
MF65 MKII
AD4-203 engine
up to 2939035 - bowl top piston - chrome liner
(Flange depth = 1mm)
91.491mm bore
|
EK12
EKM12
EKMC12
Valve Train Kit:
VK17
|
B2632
|
B2633
=41158058
745819M91
Suit chrome bore
|
B6146
=68332
743824M91
|
B7540
=31358308
732638M1
|
|
MF65 MKII
AD4-203 engine from 2939036 - bowl top piston - Cast Iron liner
(Flange depth = 4mm)
91.491mm bore
|
EK13
EKM13
EKMC13
Valve Train Kit:
VK17
|
B2146
|
B2619
=41158057
745818M91
|
B7541
=31358345
739043M1
|
B7550
=3135
8323
7341
97M1
B8550
.030" O/SIZE
|
|
MF165 AD4-203
engine
Identify By:
exhaust is on LH side
91.491mm bore with Rope Rear Seal
ie. up to 203AU109488
|
|
MF165 AD4-203
engine
Identify By:
exhaust is on LH side
91.491mm bore with Lip Rear Seal
ie. from 203UA109488L
|
EK13
EKM13
EKMC1310
Valve Train Kit:
VK17
|
|
MF165 A4-212
engine with rope rear seal
ie. up to 212UA187118
Identify By: exhaust
is on RH side
Early engines had 3 ring pistons.
Late 4 ring pistons should be used if rebuilding engine
98.476mm bore
|
EK14
EKM14
EKMC14
Uprates engine to latest 4 ring piston. Valve Train Kits:
STD = VK6
0.003" O/Size
= VK7
|
B2988
Latest 4 ring type
MUST FIT FULL SET
|
B2620
Universal ring set
Suits 3 or 4 ring pistons
=41158044
745763M91
41158041
|
B6988
=86721
783249M91
4 Ring piston
Must fit FULL SET if replacing 3 ring
pistons
|
B7543
=31358441
[flanged liner]
|
B7547
=313
58324
7346
44M1
|
|
MF165 A4-212
engine
Lip Rear Seal
ie. from 212UA187118L
Identify By: exhaust
is on RH side
Early engines had 3 ring pistons.
Late 4 ring pistons should be used if rebuilding
engine.
|
EK14
EKM14
EKMC1410
Uprates engine to latest 4 ring piston.
Valve Train Kits:
STD = VK6
0.003" O/Size
= VK7
|
