Ref.
|
Part
No.
|
Replaces
|
Description
|
Application
|
|
1
|
B356
|
K907008
|
Stay
Bar Pin 3/4" Thread dia.
|
880-990-995-1200
|
|
B460
|
K912228
|
Stay
Bar Pin 5/8" Thread dia.
|
770-780-885
|
|
2
|
B316
|
Long
Type Cat. 1 Top Link adjustment 24" (610mm) - 34" (864mm)
|
Early
Cropmaster
|
|
B312
|
Short
Type Cat. 1 Top Link adjustment 20" (508mm) - 30" (762mm)
|
770-780-(880-885
if Cat. 1 Pins)
|
|
B315
|
Short
Type Top Link adjustment 21" - 31"
Cat. 1 Tractor end Cat. 2 Implement end
|
All
White Colour Tractors up to 1212.
For Heavy Duty - use Heavy Duty link
below + B353 Bush
|
|
B1
|
Heavy
Duty Link Cat. 2 both ends
B353 Cat. 2 - Cat. 1 Bush may be required
|
Heavy
Duty applications ripping etc
|
|
3
|
|
SEE
HYDRAULIC TOP LINKS
|
Suits
All Models
|
|
4
|
|
|
5
|
B73
|
K912936
|
Top
Link Pin 3/4" x 3" effective
|
Tractor
end ALL models up to 1212
|
|
6
|
B76
|
K65690
|
Top
Link Pin 1" x 3 7/16"
|
Implement
end ALL Cat. 2
application i.e. 880 upwards
|
|
B74
|
K903981
|
Top
Link Pin 3/4" x 3 7/8" effective
|
Implement
end ALL Cat. 1 Application
|
|
7
|
B328
|
|
Cat.
1 Weld on Ball End
|
ALL
Cat. 1 (7/8") link ends
|
|
B329
|
|
Cat.
2 Weld on Ball End
|
ALL
Cat. 2 (1 1/8") link ends
|
|
8
|
B51
|
K900054
|
Low
Link Pivot pin - 2 hole
|
880
Selectomatic
(White colour)
|
|
B54
|
|
Link
Pivot pin
Stronger equivalent to B51 - 1 hole
|
|
9
|
B2979
|
K922634
|
Stepped
Pivot Pin
|
White
colour 990-995
|
|
10
|
B7190
(3/4" dia bar)
|
K921690
short type
|
Stay
Bar Assembly
(All parts interchange with original)
|
770-780
+ Early 880 & Early 885
|
B7191
(1" dia bar)
|
K912766
K954646
long type
|
850-Late
880-Late 885-990-995-1200-1212
|
|
11
|
B7192
|
K912234
|
Centre
Bar 3/4" x 16 15/16" (430mm)
|
770-780
+ Early 880 & Early 885
|
|
B7193
|
K901815
|
Centre
Bar 1" x 20 7/8" (530mm)
|
850-Late
880-Late 885-990-995-1200-1212
|
|
12
|
B7194
|
K901818
|
L.H.
Thread Ball End 1"
|
|
B7195
|
K901821
|
R.H.
Thread Ball End 1"
|
|
B7196
|
K912230
|
L.H.
Thread Ball End 3/4"
|
770-780
+ Early 880 & Early 885
|
|
B7197
|
K912232
|
R.H.
Thread Ball End 3/4"
|
|
13
|
B7068
|
K940508
K940515
|
Heavy
Duty Levelling Box Assembly
Special Design - 1" dia shaft
|
780-880
Selectomatic-885
990 Selectomatic-995
|
|
14
|
B53
|
K903399
|
Levelling
Fork Pin 5/8" x 1 5/8" effective
|
770-780
|
|
15
|
B3
|
K66408
|
Linch
Pin 5/16" (8mm)
|
Stay
Bar Pin ALL Models
|
|
16
|
B6
|
K920359
|
Linch
Pin 7/16" (11mm)
|
Various
Linkage Pins
|
|
17
|
B121
|
K902280
|
Linkage
Drawbar - Cat. 1
|
ALL
Cat. 1 Applications
|
|
B124
|
|
Linkage
Drawbar - Cat. 2
|
ALL
Cat. 2 Applications
|
|
18
|
B2662
|
|
Drawbar
Pin 1 1/8" x 4 3/4" effective pin + handle
|
ALL
1 1/8" Swinging Drawbars
|
|
B412
|
|
Drawbar
Pin 1 1/8" x 6 1/4"
|
Longer
alternative for B2662
|
|
B410
|
K916566
|
Drawbar
Pin 1" x 6 1/4"
|
ALL
1" Swinging Drawbars
|
