APPLICATION
|
ENGINE
KIT
|
PISTON / LINER
KIT (1 CYL)
|
RING SET
(1 CYL)
|
PISTON
|
LINER
|
LINER
''O'' RING
|
BD144 4 cyl engine
3 3/8" bore
B250, B275, B276, 354
|
Very early B250
with rope rear
seal requires
mods. for EKM
Kits.
See Crankshaft page
|
B3610
=
31147
75R91
(3 3/8'' bore)
|
B6456
=
3044486R3
Suits BD154 Eng. only
(3 1/2'' bore)
|
B7556
=
3044481R3
Suits BD154
Engine only
(3 1/2'' bore)
|
B7508
(4 req)
|
BD154 4 cyl engine
3 1/2" bore
374, 384, A414, B414, 434, 444 |
B2622
=
31147
78R91
(3 1/2'' bore)
|
|
*NOTE: This kit uprates
BD144
engine to
3 1/2'' (89mm) bore.
|
For BD144 (3 3/8'' bore) Eng.
fit 4 of B2456 3 1/2 '' bore kits.
|
|
D179 3 cyl engine
3 7/8" (98.425mm) bore
454, 484, 485, 495, 640,
523, 533, 633, 3220
|
EK20
EKM20
|
B5084
=
31395
91R96
includes ALL
''O'' rings
identify
by 15/16"
(24mm)
deep
piston bowl
|
B7402
=
32184
16R91
ONLY suits engines
with 3 ring piston
and tapered
(wedge type)
top ring.
i.e. late type pistons
|
B6084
(Bonded insert type)
= 3139591R96
NOTE: Replace full set
15/16" (24mm) deep piston bowl
Do not confuse with
D206, D310 engines (below) which have
shallow 25/32"
(20mm) piston bowl
|
B7557
=
3139592R2
Identify by
8 1/2"
(216mm) length
|
B7506
pair of ''O''rings
suits all
models
(Single cyl set)
|
|
D239 4 cyl engine
3 7/8" (98.425mm) bore
724, 744, 745, 833, 574, 674, 684, 685,
695
|
EK21
EKM21
EKMC21
|
|
D358 6 cyl engine
3 7/8" (98.425mm) bore
866, 886, 956,1046, 1055, 1056, 1255, 3288
|
EK22
EKM22
|
D155 3 cyl engine
3 7/8" (98.425mm) bore
385, 395, 3210, 353, 383, 423, 433, 453, 533,
440, 540 (3 cyl) |
EK96
EKM96
|
B7721
includes ALL
''O'' rings
identify by
25/32"
(20mm)
deep
piston bowl
|
B7719
(Bonded insert type)
NOTE: Replace full set
identify by 25/32" (20mm) deep
piston bowl
|
B7720
=
3139587R3
Identify by 7.9" (201mm) length
|
|
D206 4 cyl engine
3 7/8" (98.425mm) bore
identify by 25/32" (20mm) deep piston bowl
474, 554, 654, 584, 585, 595
624, 733, 740, 3230
|
EK94
EKM94
|
|
D310 6 cyl engine
3 7/8" (98.425mm) bore
identify by 25/32" (20mm) deep piston bowl
756, 686, 786, 696,
766 (with D310 engine),
|
EK95
EKM95
|
D268 4 cyl engine
3.937" (100mm) bore
844, 845, 884, 885, 895, 4230 |
EK108
EKM108
|
B7090
=
32184
61R95
|
B7088
=
31449
77R91
Suits 3 ring piston
|
B7087
|
B7089
=
3144682R3
|
D402 6 cyl engine
3.937" (100mm) bore
1455, 1455XL |
EK109
EKM109
|
|
Perkins A4 - 212 engine
475
|
EK14
EKM14
EKMC14
|
B2988
MUST
fit full set
|
B2620
|
B6988
|
B7543
Finished
B7547
Semi finished
|
N/R
|
